a2 Blackmagic Design, based in fremont, California, has recently announced their new ATEM Teleision Studio HD. It is a broadcast quality live production switcher that can be utilized by both professional and broadcast AV users and features such advanced technology as 8 inputs, multi view, aux, and program outputs, analog audio inputs, built in talkback, two flash based media players, incredible creative transitions, and a DVE for effects. ATEM Television Studio HD is perfect for everything from professional broadcast studio shows and broadcast sports, to customers working on video blogs, gaming videos, internet talk shows, weddings, concerts, seminars and more. It also features resynchronization on every input so switching is completely glitch free. That means customers can even use it as a front end controller for AV systems and cleanly switch between sources with the press of a button. Blackmagic Design, whose corporate is located in Fremont, California, has a total of six office located world wide. Blackmagic Design creates the world’s highest quality video editing products, digital film cameras, color correctors, video converters, video monitoring, routers, live production switchers, disk recorders, waveform monitors and real time film scanners for the feature film, post production and television broadcast industries. Blackmagic Design’s DeckLink capture cards launched a revolution in quality and affordability in post production, while the company’s Emmy™ award winning DaVinci color correction products have dominated the television and film industry since 1984. The new ATEM Television Studio HD replaces the original and extremely popular ATEM Television Studio. It features four 3G-SDI and four HDMI inputs so customers can connect a total of up to 8 different sources such as professional SDI broadcast cameras, consumer HDMI cameras, computers and even video game consoles. ATEM Television Studio HD is compatible with all SD and HD formats up to 1080p60. There are two channels of analog audio in, RS-422, Ethernet and a built in IEC power supply, along with program and auxiliary outputs. Customers also get both SDI and HDMI multi view outputs so they can monitor all sources, preview and program outputs, along with labels, audio meters and more, all on a single big screen television or broadcast monitor. a4 Grant Petty, CEO at Blackmagic Design said of this new studio that, “The original ATEM Television Studio has been a huge hit and is extremely popular with our customers. The exciting thing about new ATEM Television Studio HD is that it has even more inputs and more features than before, but now makes it possible for customers to create an entire HD program right from the front panel! When it comes to creating HD programs from live events, there simply is no faster, simpler or more affordable way to do it.” Some of the great features on the new ATEM Television Studio HD include...
  • 4 x 3G-SDI and 4 x HDMI inputs for a total of 8 inputs, all with auto re‑sync.
  • Supports all video formats from SD to 720p, 1080i and 1080p HD up to 60fps.
  • 1 x built in multi view for 8 sources, as well as preview and program.
  • Built in media pool graphics storage for 20 RGBA stills.
  • Built in DVE with 3D borders and drop shadow.
  • Transitions include cut, mix, dip, SMPTE wipes and more.
  • 1 upstream keyer including chroma keyer plus 2 downstream keyers.
  • 1 auxiliary output with front panel aux switching buttons and LCD screen for viewing.
  • Built in audio mixer live mixes embedded audio from all video inputs and independent audio inputs.
  • Balanced XLR stereo analog audio inputs .
  • Internal sources include black, color bars, two color generators and 2 media player outputs.
  • Ethernet connection for computer connection. Mac and Windows control panel software included.
  • Compatible with all ATEM Broadcast Panel control panels when hardware panel is required.
  • Black Burst and HD-Tri-Sync genlock input for integration into large systems.
  • Compact â…” rack unit size is perfect for when in a portable solution is required.
  • Desktop or rack mountable using the optional Teranex Mini Rack Shelf.
 ATEM Television Studio HD also includes a built in talkback converter for SDI cameras. The talkback information is sent back to the camera via the SDI program return feed on the rarely used SDI audio channels 15 and 16. When working live with a reporter in the field, there can be a slight delay that causes them to hear themselves as an echo in their headset. ATEM Television Studio HD includes a new mix minus feature that sends back all the program audio except their own voice, so they don’t hear a distracting echo of themselves while reporting.
The ATEM Television Studio HD software control also has a complete camera control section for remotely controlling cameras over the SDI program return feed. Blackmagic Studio, Micro and URSA Mini cameras are all compatible with the SDI control protocol. These cameras also feature built in DaVinci Resolve primary color correct that can be remote controlled, making it possible to balanced camera color and create unique looks, all from the switcher. In addition, customers can adjust focus and iris on compatible lenses, change camera settings, and even remote control PTZ heads.
In addition, ATEM Television Studio HD has a built in media pool that can store 20 graphics that can be used with the two built in media players. The media pool uses flash memory, so images are saved even after the power is turned off. That means customers can create completely custom graphics to use in their own programs. In addition, there is an upstream keyer with full chroma keying for green screen shots so customers can add weather maps, graphics, or even virtual sets. The upstream keyer works with chroma, patterns, shapes and linear keys.
